VICI DBS HP Plus 500 Tower Nitrogen Generator

HP Plus 500 Tower Nitrogen Generator

The new HP Plus 500 Tower Nitrogen Generator produces high purity nitrogen for all major applications in analytical laboratories. Nitrogen generators eliminate the problems associated with the handling of high pressure gas tanks and reduce the cost of high purity nitrogen immediately. The N2-TOWER Plus series of nitrogen generators use air from a separate compressor and remove the oxygen to less than 10ppm (hydrocarbons to 0.1ppm is optional). The guaranteed flow rate of pure nitrogen is 500 ml/min.

HP PLUS 500 TOWER FEATURES:
▪︎ Flow rate 500 ml/min
▪︎ Purity 99.999%
▪︎ Pressure up to 5 bar (75 psi)
▪︎ Space saving design
▪︎ Propriotory carbon molecular sieve
▪︎ Optional hydrocarbon removal for GC applications
▪︎ Ideal for GC carrier gas including ECD, make up gas, TOC, DSC, and ELSD applications
▪︎ 2 year standard warranty

Part# DB-N2T-500-EU (220V/50Hz)
Part# DB-N2T-500-US (115V/60 Hz)

GC APPLICATIONS
▪︎ GC-FID CARRIER & MAKE-UP GAS
▪︎ ECD
▪︎ ELSD
▪︎ INCUBATORS
▪︎ TGA & DSC

The following option is available:
▪︎ Catalytic oven

Flow ml/min 500
Purity 99.999%
Hydrocarbon purity (measured as methane) n/a
Dewpoint -50 oC
Outlet pressure bar (psi) up to 5 max (75)
Inlet pressure bar (psi) 7 to 10 (100 to 160)
Actual inlet air requirement liters -at 8 bar 11
Recommended compressor air inlet at 8 bar 22
Pressure drop bar (psi) 1.5 (22)
Inlet air quality Clean dry compressed air ISO8573-1:2010 Class 3.2.2
Technology Carbon molecular sieve
Warm up time (minutes) 60 minutes
LED indicators Power on / off, system ready, errors
Electrical supply 110-120V 60Hz / 220-240V 50Hz
Power consumption watts 12
Noise level Minimal
Product dimensions mm (inches) 140W x 490H x 630D (13.7Wx 29Hx 13.7D)
Product weight kg (lb) 15(17.6)
Shipping dimensions mm (inches) 770W x 590H x 410D (30.3Wx 16.1Hx 23.2D)
Shipping weight kg (lbs) 20 (44)
Operating temperature oC (oF) 15 to 35 (59 to 95)
Inlet connection 1/4" compression
Outlet connection 1/8"compression
Certification CE, MET, FCC
